Auto Hanger
- It effectively removes SCALE and BURR attached to the surfaces of gears and various heat treatments for automobiles.
- It can change the speed of conveyor and IMPELLER for product conveyance, effectively removing scales and performing SHOT PEENING.
- All processes can be automated unattended.
- It is possible to install a rotating device to rotate the product and to work with less power.
- Body CABINET is made of Hi-Cr or Hi-Mn, so it has excellent durability.
Specifications
| Division/MODEL NO |
MSAH-700 |
| HANGER SIZE |
Φ700 |
| IMPELLER UNIT |
Φ380×20HP×2SET |
| WORK TIME |
20 seconds to 5 minutes |
| SPEED CONTROL |
INVERT method |
| DUST COLLECTOR |
35M3/MIN |
