Air Blast Type

  • It is a facility to remove welding slides and scales before PAINT work to improve PAINT adhesion to large steel structures, shipbuilding blocks, etc.
  • The conveyor can be automatically transferred by installing the conveyor system.
  • By installing a bogie and transferring the workpiece, the working efficiency can be increased.
  • VACUUM RECOVERY can be installed to efficiently recover the abrasive accumulated in the product.

Specifications

Division/MODEL NO MSAB-77 MSAB-127 MST-187
CABINET SIZE 7000W×7000H×16000L 12000W×7000H×20000L 18000W×7000H×24000L
DOOR SIZE 4500W×5000H 10000W×5500H 16000W×5500H
POWER 120HP 150HP 200HP
AIR Consumption 4M3/Min 4M3/Min 4M3/Min
DIAMETER OF NOZZLE Φ12.7×3SET Φ12.7×5SET Φ12.7×8SET
DUST COLLECTOR 900M3/MIN 1100M3/MIN 1500M3/MIN
